Мини-экскаватор JT25 Mini Excavator

JT25 Mini Excavator Description

The JT25 Mini Excavator is a crawler excavator with an operating weight of 2500kg, powered by a KUBOTA D1105 14.2Kw engine, which is powerful, stable and reliable. The fully hydraulic system with boom swing function realizes precise control and greatly improves the working efficiency. The unique inverted upper arm structure and cast side swing head not only give the machine a smooth and beautiful appearance, but also significantly enhance the structural strength to ensure stability and durability during long-time high-intensity operation. The dual-speed design allows the equipment to quickly switch operating speeds according to different working conditions, further optimizing the construction efficiency. In addition, the rich optional configurations can fully meet the user's individual needs, making it an ideal choice for municipal engineering, landscape construction, agricultural development and other scenarios.

JT25 Mini Excavator Parameters

Basic parameters

Operating weight: 2500kg, solid body weight to ensure operational stability, and at the same time has good passability and cross-country ability.

Model: Crawler Model, the crawler design enables it to adapt to muddy, rugged, soft and other complex terrain, and easily cope with all kinds of construction environments.

Power System

Engine: KUBOTA D1105, power 14.2Kw. The engine has mature technology, excellent power output and fuel economy, which effectively reduces the long-term cost of use and ensures the continuous and stable operation of the equipment.

Core performance configuration

BOOM SWING Function: The boom can be swung flexibly to complete the work in narrow space without frequent movement of the body, especially suitable for urban alley construction, indoor remodeling and other space-restricted scenarios, which significantly improves the operating efficiency.

Full Hydraulic System: The full hydraulic system brings precise and smooth operation experience, sensitive response to digging, lifting and slewing, and high control accuracy, capable of efficiently completing various complex work tasks.

Innovative structural design:

The upper arm adopts inverted structural device, which optimizes the force conduction path, reduces stress concentration, and improves structural reliability and durability.

The connecting side pendulum head adopts the whole casting molding process, which is more beautiful in appearance than the welded parts, and the structural strength is increased by about 35%, which effectively prolongs the service life of the equipment and reduces the risk of malfunction.

Dual-speed function: It supports high and low speed switching, providing strong torque in low-speed mode, which is suitable for heavy-duty excavation, crushing and other operations; and enhancing the speed of action execution in high-speed mode, which can quickly complete the tasks of material handling, site leveling and other tasks, and flexibly adapts to the needs of different working conditions.

Optional Configurations

Closed cabin: Closed design creates a comfortable and safe working environment for operators, effectively isolating noise, dust and bad weather. It supports color customization to meet individual needs; equipped with air conditioning system to ensure the comfort of long-time operation.

Telescopic track: The width of the track can be adjusted according to the need, contracting the track to facilitate passage in narrow areas, and expanding the track to enhance stability in complex terrain or heavy-duty operations, further expanding the application scenarios of the equipment.

Multifuction Accessories:

Quick connector: realizes quick replacement of accessories, greatly shortens the time of equipment changeover and improves the overall construction efficiency.

Hydraulic Thumb Clamps: Grab and carry irregular objects such as stones and wood accurately, enhancing the flexibility of the equipment in material handling operations.

Drilling: Auger, suitable for drilling operations such as tree planting, fence piling and pipeline drilling.Crushing: Hammer, can crush concrete, rock and other hard objects to meet the needs of construction and demolition, mining excavation and other projects.

Excavation: Equipped with different sizes of buckets such as 200mm, 500mm, 600mm, 801mm, etc. Small size buckets are used for fine excavation, and large size buckets can enhance single excavation volume to meet the requirements of diversified excavation work.

Grabber: Grabber is used to grab and carry loose or irregular materials, such as scrap iron, garbage and so on.

Leveling: Rake, can be used for land leveling, debris removal, site shaping and other operations.

Loosening: Ripper, capable of loosening hard soil or breaking up shallow rocks to prepare for subsequent excavation.
